AsRock X670E Pg Lightning AM5 ATX Motherboard (X670E-Taichi)
Brand: ASrock
SKU: X670E-PG-Lightning
Price: ₹25,549 (inclusive of GST · genuine product with warranty)
CPU:SUPPORT AMD AM5 RYZEN 7000 SERIES PROCESSORS CHIPSET:AMD X670 MEMORY:DUAL CHANNEL;4*DDR5;MAX 128GB SLOT:1*PCIE5.0X16;1*PCIE4.0X16;1*PCIE4.0X1;1*M.2 GRAPHICS:INTEGRATED AMD RDNATM2 GRAPHICS(ACTUAL SUPPORTY VARY BY CPU)
Specifications
| color | Black |
|---|---|
| Socket | AM5 |
| Platform | AMD |
| RAM type | DDR5 |
| Warranty | 3 Years |
| Product Type | Normal |
| EAN / UPC Code | 7078282186854 |
| Motherboard Size | ATX |
About this product
ASRock X670E PG Lightning Support AMD AM5 RYZEN 7000 Series Processors Motherboard
Feature
Supports AMD Ryzen™ 7000 Series Processors
14+2+1 Phase Power Design, SPS
4 x DDR5 DIMMs, supports up to 6600+(OC)
1 PCIe 5.0 x16,2 PCIe 4.0 x16,1 PCIe 4.0 x1,1 M.2 Key-E for WiFi
Graphics Output Options: 1 HDMI, 1 DisplayPort
Realtek ALC897 7.1 CH HD Audio Codec, Nahimic Audio
1 Blazing M.2 (PCIe Gen5x4),1 Hyper M.2 (PCIe Gen4x4),1 Ultra M.2 (PCIe Gen3x4 & SATA3),1 M.2 (PCIe Gen4x2),4 SATA3
2 USB 3.2 Gen2x2 Type-C (1 Rear, 1 Front),1 USB 3.2 Gen2 Type-A (Rear),10 USB 3.2 Gen1 (6 Rear, 4 Front)
Realtek 2.5G LAN
Build for The Most Advanced PC
AM5 Changes Everything
AMD EXPO™ Technology
Optimized VRM Design
SPS (Smart Power Stage)
Asrock Dr.MOS design features the latest SPS (Smart Power Stage) technology. It’s optimized for monitoring current and temperature of each phase, thus delivering smoother and neater power to the CPU with enhanced performance and OC capability.
14+2+1 Power Phase Design
Featuring sturdy components and completely smooth power delivery to the CPU. Plus, it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well.
Premium PCB Design
Server Grade Low Loss PCB
The server grade low loss PCB improves signal integrity, allowing motherboard to support PCIe 5.0 for both graphics card and M.2 SSD, it also improves memory OC potential to deliver the most extreme memory performance.
8 Layer PCB
The 8 Layer PCB provides stable signal traces and power shapes delivering lower temperature and higher energy efficiency, ensures a reliable and long-lasting system while delivering ultimate performance without any compromise.
Extreme Overclocking Performance
DDR5 EXPO & XMP Support
Derived from the “built for stable and reliable” designing concept, ASRock does not compromise on any details. All X670E motherboards are built with 8-Layer and premium low-loss materials, enthusiasts are able to enjoy the boost of DDR5 memory overclocking performance up to 7600MHz and beyond by enabling the pre-tested profiles. Make sure the memory modules are AMD EXPO™/ Intel ® XMP capable and overclocking can be made so affordable, satisfying and absolutely no sweat at all.
Blazing OC Tuner
The Blazing OC Tuner allows AM5 CPU to switch between OC mode and PBO(Precision Boost Overdrive) mode when the CPU current hits threshold. Anything above current threshold will engage manual OC mode; if below current threshold then will engage Precision Boost Overdrive mode. This idea is to combine overclocking on all cores and automatic boost on a single core to get the best performance out of your CPU. There is no need to enter BIOS to setup up, you can modify all the settings on time under OS.
AMD PBO Technology
PBO(Precision Boost Overdrive) is an automatic performance-maximizing technology that is able to improve your PC’s performance by raising clock speeds based on the conditions inside your PC, AMD’s processors is equipped with intelligent thermal sensors designed to analyze conditions inside your PC and make the “go faster” decision as often as possible, please ensure system cooling is sufficient before enabling PBO.
DDR5 Memory with Protection Circuit
Due to the unique electrical architecture of DDR5 DIMM, there’s a high risk of damaging the memory module if AC power isn’t disconnected properly during removal or installation. To prevent this, ASRock has implemented a trouble free protection circuit on every DDR5 motherboard, lowers the risk of damaging your memory module.
High Speed M.2 Solution
PCIe Gen5 Blazing M.2
The Blazing M.2 accommodates the latest PCI Express 5.0 standard to perform twice the bandwidth compared to previous generation, with a breathtaking 128GB/s transfer speed, it is ready to unleash the full potential of future ultrafast SSDs.
