Asus TUF Gaming B650 Plus WIFI Motherboard

Brand: Asus

SKU: TUF-GAMING-B650-PLUS-WIFI

Price: ₹22,099 (inclusive of GST · genuine product with warranty)

B650 Plus AMD AM5 socket: Ready for AMD Ryzen 7000 Series desktop processors B650 Plus Enhanced power solution: 12+2 teamed power stages, 8+4 ProCool sockets, alloy chokes and durable capacitors for stable power delivery Next-gen connectivity: M.2 PCIe 5.0, USB 3.2 Gen2x2 Type-C, front USB 3.2 Gen 1 Type-C, USB4 support

Specifications

About this product

Asus TUF Gaming B650 Plus WIFI Motherboard

ASUS TUF GAMING B650-PLUS WIFI AMD Ryzen AM5 Micro-ATX motherboard, 14 power stages, PCIe 5.0 M.2 support, DDR5 memory, WiFi 6 and 2.5 Gb Ethernet, USB4 support and Aura Sync

Asus TUF Gaming B650 Plus WIFI Motherboard ASUS is one of Fortune magazine’s World’s Most Admired Companies and is one of the top motherboard and gaming brands, as well as a top-three consumer notebook vendor. ASUS is driven by passion and innovation and dedicated to creating quality products for a future smart life, designing and manufacturing products that perfectly meet the needs of today’s digital home, office and person. Our wide portfolio includes MG248Q, Chromebox and a range of devices and components, along with AR and VR.

B650 Plus AMD AM5 socket: Asus TUF Gaming B650 Plus WIFI Motherboard Ready for AMD Ryzen 7000 Series desktop processors

Enhanced power solution: Asus TUF Gaming B650 Plus WIFI Motherboard 12+2 teamed power stages, 8+4 ProCool sockets, alloy chokes and durable capacitors for stable power delivery

B650 Plus Enhanced power solution: Asus TUF Gaming B650 Plus WIFI Motherboard 12+2 teamed power stages, 8+4 ProCool sockets, alloy chokes and durable capacitors for stable power delivery

Made for online Gaming: WiFi 6, Realtek 2.5 Gb Ethernet and TUF LANGuard

Two-way AI Noise Cancelation: Asus TUF Gaming B650 Plus WIFI Motherboard Reduces background noise from the microphone and audio output for crystal-clear communication in games or video conferences

Comprehensive cooling: Enlarged VRM and PCH heatsinks, M.2 heatsinks, hybrid fan headers and Fan Xpert 2+ utility in Armoury Crate

KSP-7: Aura Sync RGB effects: Stylish edge lighting design, addressable RGB headers and RGB strip header support.

Cooler By Design

1. Enlarged VRM Heatsink

The extensive surface area of this heatsink covers the VRMs and chokes to improve heat dissipation.

2. Optimized M.2 Heatsink Design

All M.2 slots have dedicated heatsinks, keeping M.2 SSDs at optimal operating temperatures to ensure consistent performance and reliability.

DRAM Overclocking Performance

DDR5 OC 6400

Comprehensive memory tuning options are the cornerstone of TUF GAMING motherboards. With TUF GAMING B650 Plus motherboards, you can extract all of the potential out of your DDR5 modules, whether they’re from an extreme-speed kit or an entry-level set that would otherwise be locked.

PCIe 5.0 Support

TUF GAMING B650 Plus motherboards also feature one PCIe 5.0 M.2 slot to enjoy the fastest data transfers of up to 128 Gbps*, and all M.2 slots support for NVMe RAID configurations to take advantage of the latest available speeds.

*Actual transmission speed will be lower than theoretical maximum speed.

Connectivity

TUF-GAMING B650 Plus motherboards reach new heights of performance potential with the latest version of PCI Express, while an arsenal of USB ports includes three Type-C connections, and Thunderbolt (USB4) expands compatibility and bandwidth even further.

1. USB 3.2 Gen 2×2 Type-C

2. PCIe 5.0

3. Front USB3.2 Gen 1 Type-C

4. USB4 Support

Teamed Power Stages

Asus TUF Gaming B650 Plus WIFI Motherboard 12+2 power stages are each rated to handle 60 amperes, combining high-side and low-side MOSFETS and drivers into a single package to deliver power, efficiency and stable performance for all compatible AMD processors.

ESD Guards

Asus TUF Gaming B650 Plus WIFI Motherboard ESD Guards prolong the life of components while preventing damage from electrostatic discharge, providing protection for up to +/- 10 kV of air discharge and +/- 6 kV of contact discharge — greatly surpassing the respective industry standards of +/- 6 kV and +/- 4 kV. Surface-mounted TVS diodes in a dual in-line package help protect your PC from voltage spikes.

WiFi 6

Asus TUF Gaming B650 Plus WIFI Motherboard the WiFi 6 module is compatible with the 802.11ax standard and pushes theoretical peak bandwidth up to an incredible 1.2 Gbps. Perhaps more importantly for power users, it’s optimized for more efficient operation on crowded networks with a lot of competing traffic. Pair your motherboard with ASUS WiFi 6 routers to fully experience the networking potential of WiFi 6.

Realtek 7.1 Surround Sound

The unique audio codec designed in close collaboration with Realtek for TUF GAMING B650 motherboards features an unprecedented 108 dB signal-to-noise ratio for the stereo line out and a 103dB SNR for the line in, providing pristine audio quality.

M.2 Q-Latch

The innovative Q-Latch makes it easy to install or remove an M.2 SSD without the need for specific tools. The design employs a simple locking mechanism to secure the M.2 SSD, neatly eliminating the need for screws.
