GAMDIAS HELIOS E1-600 600W 80+ Non-Modular ATX Power Supply (120mm Fan, Dual PCIe, 3-Year Warranty)
Brand: Gamdias
Price: ₹8,999 (inclusive of GST · genuine product with warranty)
The GAMDIAS HELIOS E1-600 is a 600 W non-modular ATX power supply that delivers up to 80%+ efficiency with automatic fan speed optimization for quieter operation. It features a stealth black design, 120 mm cooling fan, support for Intel C6/C7 power states and a solid set of protection circuits (OVP, UVP, OPP, SCP) for stable and safe power delivery. With dual 6+2-pin PCIe connectors, five SATA, two Molex and a 3-year warranty, the HELIOS E1-600 is a reliable choice for budget and mid-range gamin
Specifications
| Size | 120mm |
|---|---|
| Type | Power Supply |
| Modular | Non modular |
| Wattage | 600W |
| Automatic Fan Speed Optimization | 120 mm fan automatically adjusts its speed according to internal temperature, balancing cooling and noise |
About this product
The GAMDIAS HELIOS E1-600 is a 600 W non-modular ATX power supply that delivers up to 80%+ efficiency with automatic fan speed optimization for quieter operation. It features a stealth black design, 120 mm cooling fan, support for Intel C6/C7 power states and a solid set of protection circuits (OVP, UVP, OPP, SCP) for stable and safe power delivery. With dual 6+2-pin PCIe connectors, five SATA, two Molex and a 3-year warranty, the HELIOS E1-600 is a reliable choice for budget and mid-range gaming or office PCs.
600 W with 80%+ efficiency: Meets up to 80% efficiency, reducing wasted power and heat compared to generic PSUs.
Automatic fan speed optimization: 120 mm fan automatically adjusts its speed according to internal temperature, balancing cooling and noise.
Stealth black, non-modular design: Fully black housing with sleeved non-modular cables for durability and a clean look in most cases.
Modern platform with protections: ATX12V v2.4 platform with support for C6/C7 power states and OVP, UVP, OPP, SCP protections for safer long-term use.
Dual PCIe and ample peripherals: Provides 2 × 6+2-pin PCIe for GPUs, 5 × SATA, 2 × Molex and 1 × Floppy, covering typical mid-range builds with multiple drives.
Specification
Detail
Brand
GAMDIAS
Model
HELIOS E1-600
Form Factor
ATX12V v2.4
Total Power
600 W
Efficiency
Up to 80% efficiency (80+ level)
AC Input
220–240 V / 6 A / 47–63 Hz
DC Outputs
+3.3 V, +5 V, +12 V, -12 V, +5 Vsb
Max Output Current
+3.3 V: 16 A; +5 V: 16 A; +12 V: 40.5 A; -12 V: 0.3 A; +5 Vsb: 2.5 A
Max Combined Power
+3.3 V/+5 V: 100 W; +12 V: 486 W; -12 V: 3.6 W; +5 Vsb: 12.5 W
Modular Type
Non-modular
Fan
120 mm fan with automatic speed control
Main Power
1 × 20+4-pin ATX
CPU Power
1 × 8-pin (4+4) EPS/CPU
PCIe Power
2 × 8-pin (6+2) PCIe
SATA Power
5 × SATA
Molex Power
2 × 4-pin Molex
